The FIRA B160 series infrared thermal imager, high sensitivity 160×120 resolution infrared detector. It is an ergonomically designed handheld temperature measuring thermal imager, small and light and simple to operate. Quickly measure hot spots surface temperatures and accurately locate the faults. A high quality thermal camera with a thermometer price.
SPECIFICATION B160
Image Performance
- Detector Type Uncooled VOX
- Resolution 160×120@17μm
- Super Resolution Up to 320×240 pixels
- Spectral Range 7.5 μm ~ 14 μm
- Wavelength 50Hz
- NETD ≤0.05°C@30°C
- FOV 38° × 50°
- Minimum Measurement Distance 15cm
Display
- Screen 2.4-inch LCD screen
- Digital Camera 5-megapixel, with built-in LED lights
- Palette White hot, black hot, iron red, rainbow
- IR Image Format JPEG
- Image Storage Micro SD card 8GB
- Transfer Interfaces Type-C,TF card, HDMI, Bluetooth, and WiFi
Measurement & Analysis
- Temperature Measurement Range -20℃~550℃
- Temperature Accuracy ±2℃ or ±2% (Use the maximum value)
- Temperature Measurement Mode 3 temperature measurement points (center point, maximum temperature and coldest temperature
Power supply
- Battery Type Rechargeable Lithium lon
- Battery Hours Approximately 8 hours Continuous working Time (25°C ambient temperature)
- Battery Charger 12V Micro USB Adapter
- Power Management Adjustable; off,5 minutes, 10 minutes, 20 minutes
Environmental
- Working Temperature -10°C~50°C，≤95%
- Storage Temperature -40°C~70°C
- Enclosure Rating IP54
Physical Specification
- Weight ＜350g
- Dimensions 196×78×59mm
- Accessories Adapter ×1, USB cable ×1, wristband strap ×1, Micro SD card ×1, Manual
